Pad for Pipe Reinforcement
To strengthen high-stress locations, guard against damage from external loads, and maintain structural integrity, a pipe reinforcing pad, also known as a repad, is a metal plate, often composed of carbon or stainless steel, that is welded around a pipe branch junction. They distribute stress away from cutouts by acting as a saddle, especially in systems with high temperatures or pressures.
PetroSan is only manufacturer and fabricators of pipe reinforcing pad, pipe reinforcement pad, pad for pipe reinforcing, fittings reinforcement pad, reinforcement pad for pipe and fittings, tank reinforcing pad, vessel reinforcing pad, pipeline reinforcing pad, tee reinforcing pad, metal pipe reinforcing pads, pipe reinforcing saddle.
At PetroSan Oilfield Engineering Co., we’re dedicated to delivering top-notch pipe reinforcing pads or pipe reinforcing saddle that exceed industry standards. With state-of-the-art technology and a team of seasoned experts, we craft pads that provide unparalleled support and reinforcement for critical pipe connections. Our commitment to quality, precision, and customer satisfaction has earned us a reputation as a trusted partner among clients worldwide. From concept to delivery, we ensure seamless execution and timely support, backed by our rigorous quality assurance processes and competitive pricing.
A PetroSan pipe reinforcement pad, also known as a reinforcing pad or pipe saddle, is a metal plate or pad welded onto a pipe to provide additional support and reinforcement around a branch connection or nozzle.
Key purposes:
– Distribute stress concentrations
– Reduce pipe wall stress
– Prevent pipe deformation
– Increase connection strength
Commonly used in:
– High-pressure piping systems
– Large-diameter pipes
– Critical connections (e.g., headers, manifolds)
– Areas with high vibration or stress.
Pipe reinforcing pad specifications typically include:
– Material: matching pipe material (e.g., carbon steel, stainless steel)
– Size: based on pipe diameter and branch size
– Thickness: calculated based on design pressure and stress
– Shape: rectangular, circular, or custom
– Wedge angle: typically 45° or 90°
– Welding: full-penetration welds, often with specific weld procedures
– Dimensions: governed by codes (e.g., ASME B31.3, API 650)
Common standards:
– ASME B31.1 (Power Piping)
– ASME B31.3 (Process Piping)
– API 650 (Welded Tanks)
Common materials for pipe reinforcing pads include:
– Carbon steel: ASTM A516 grade 60 /70, A105, A234 WPB, A106 etc.
– Stainless steel: ASTM A240 (304, 316, 321, etc.)
– Alloy steel: ASTM A182 (F11, F22, etc.)
– Duplex stainless steel: ASTM A240 (2205, 2507, etc.)
Material selection depends on:
– Pipe material
– Service media (corrosive, erosive, etc.)
– Temperature
– Pressure
– Industry standards (ASME, API, etc.)
Installing a pipe reinforcing pad involves:
1. Preparation: clean and prepare the pipe surface
2. Marking: mark the pad location and branch connection
3. Cutting: cut the pad to size (if not pre-fabricated)
4. Welding: weld the pad to the pipe (full-penetration welds)
5. Inspection: check weld quality and pad fit
6. Testing: hydro-test or NDT (as required)
Key considerations:
– Follow welding procedures and codes (e.g., ASME B31.3)
– Ensure proper fit-up and alignment
– Use compatible materials and welding techniques
